Intelligent Machinery Condition Monitoring Laboratory

About

IMCML is dedicated towards research in the field of fault diagnosis and prognosis for rotating element. The research work mainly focuses on bearing fault detection, isolation, diagnosis, prognosis etc. The lab is equipped with bearing prognostic test system and bearing diagnostic test system and various experimental facilities.

Professor Incharge

Prof. S H Upadhyay

Professor

sanjay.upadhyay@me.iitr.ac.in

East Block, Room No:235

01332-285520

Experimental Facilities

Equipment's

Students

Placement

Bearing Test Rig

a. Speed control unit. b. Accelerometer 1. c. Load disc. d. Accelerometer 2. e. Bearing Housing 2. f. Jaw coupling. g. Proximity sensor. h. AC motor. i. Computer. j. Data acquisition unit. k. Bearing Housing 1. l. Shaft.

Bearing Prognostics Test System

Rolling element bearing test bed

Bearing Diagnostics Test System

Rolling element bearing test bed.

Motor

3-Phase, 1-hp, 3000 rpm, Volt – 410 ± 10%

BNC Cable

• 3027AM3 • Max. Temp. 185 °F • Length – 120 Inch

Variable Frequency Drive (VFD)

• 3-phase, 1-hp • Input – 380-480 volt • Amp – 3.2 • Frequency range – 0.1 – 599 Hz

Accelerometer

• 66A12-X • Sensitivity – 105.1 mV/g @ 100 Hz • 5g pk

Radial Load Arrangement

------------

Load Sensor

• Range 0 – 50 kg

Current

Alumni

Sachin P. Patel

Research Problem: An Investigation of Nonlinear Dynamic Performance of Cylindrical Roller bearing.

2017

Prashant Tiwari

Research Problem: Automated Health Assessment of Rolling Element Bearing.

2017

S.no.	Student Name	Placement location	Position
1	Dr. Akhand Rai	University of Ulsan, Korea	Postdoc
2	Dr. Divyang H. Pandya	L.D.R.P. Engineering College, Sector-14, Gandhinagar	Professor & Head (Mechanical Engineering)
3	Dr. Utkarsh A. Patel	L. D. College of Engineering, Ahmedabad	Assistant Professor (Mechanical Engineering)
4	Dr. Jignesh P. Patel	Vidush Somany Institute of Technology and Research, Kadi	Professor & Head (Mechanical Engineering)
5	Mr. Prashant Tiwari	NIT, Srinagar	Trainee Teacher
6	Mr. Salunkhe Akshay Vinayak	Schlumberger, Kalyan Area, India	Mechanical Engineer
7	Mr. Waquar Ahmed Khan	Bharat Heavy Electricals Limited	Senior R & D Engineer
8	Mr. Saravanan J.	Siemens Limited, Gurgaon, Haryana, India.	Senior Executive
9	Mr. Yadav Himanshu Kantilal	L.D.R.P. Engineering College, Sector-14, Gandhinagar	Assistant Professor
10	Mr. Patil Pravin Ganpati	General Electric (GE Aviation), Bengaluru, Karnataka, India	Lead Engineer/Technologist
