Spark Plasma Sintering Machine
Spark Plasma Sintering(SPS) is used for compacting metallic, ceramic or metal-ceramic powders to form a pellet. SPS does not need a binder and achieves high density at reduced sintering temperature and time. The powder sample is filled into a graphite die through which current is passed and the resulting pellet is a material with better mechanical properties.

Alt text
Specifications:
Model : Dr. Sinter SPS-625, Fuji Electronic Industrial Co. Ltd., Japan
Max. Current : 5000A
Max. sintering Temperature : 2000˚ Celsius
Max. sintering pressure : 100 KN
Vacuum : up to 0.006 Pa
Operating parameters depends on the sample composition and die type/size.
Sample Requirements:
Sample must be bone dry by heating in oven at suitable temperature for atleast 24 hrs. Powder sample weight: 4-10g (depends on the sample density and desired pellet dimensions)

Charges:
For Non-IITR users:
Educational institutes: ₹ 4,000 + 18% GST per sample
Govt Research labs: ₹ 8,000 + 18% GST per sample
Industry users:
⦁Testing : ₹ 10,000 + 18% GST per sample
⦁Consultancy: ₹ 15,000 + 18% GST per sample

Procedure for Sample Submission/Testing:
IITR Users:
MMED IITR users need to submit duly signed form at the office of the Officer In-charge. Non-MMED IITR users need to forward the form through Head, MMED.
For Non-IITR users: The requisition Form for SPS duly forwarded by the concerned Supervisor/Head, with details of NEFT/RTGS/UPI transfer and GST number of the concerned Institute, may kindly be sent to the postal address. E-mail Id and mobile number is to be clearly written in the application.

The Mode of Payment is only by online transfer through NEFT/RTGS/UPI. The details of account for the same is as under:
Name of A/c holder         : Dean SRIC, IIT Roorkee
Name of Bank                : Punjab National Bank, IIT Roorkee branch
Account No.                   : 4044000100031597
IFSC Code                     : PUNB0404400
MICR Code                    : 247024103

The Equipment Requisition Form can be downloaded from the website of the department

Postal address:
Samples along with online transaction details and duly signed form are to be posted to
The Head,
Dept of Metallurgical & Materials Engg,
IIT Roorkee, Roorkee – 247667,
Uttarakhand, India
Tel: 01332 284343, 285606

Do mention “Samples for SPS (Spark Plasma Sintering)” on the envelope.

Contact Details:

Professor In-Charge:
Prof. Vikram V. Dabhade
E-mail: vikram.dabhade@mt.iitr.ac.in
Tel: +91- 01332-285143

Officer In-Charge:
D. Prasad , Technical Officer
E-mail: mozhimic@iitr.ac.in
Tel: +91- 01332-284380

Room No. - 111
